Good solderability even on uneven surfaces
Features
- Flux application is not necessary.
- Applicable to hard-to-supply uneven surfaces.
- Void formation is less and heat dissipation properties are excellent.
Performance / Lineup
The flux for coating can be selected depending on the purpose of use
| Flux | Type | IPC classification | surface material to be applied on |
|---|---|---|---|
| SFC1 | R | ROL0 | Nickel-/gold-plated material, silver, copper, and other materials |
| SFC2 | Halogen-free | ROL0 | Nickel-/gold-plated material, silver, copper, and other materials |
| SFC3 | RMA | ROL1 | Nickel-/gold-plated material, silver, copper, and other materials |
| SFC4 | RA | ROL1 | Nickel, brass, copper, tin, and other materials |
| SFC5 | RA | ROM1 | Nickel, brass, copper, tin, and other materials |
Colored types are also available.
Write to us to know more about the various flux types.
If necessary, you can use a commercially available flux cleaner to remove the flux residue.
